OVERVIEW

Key Advantages and Features

• Precision & Accuracy: 1/2 MOA click value and ±140 MOA windage/elevation adjustment allow fine-tuned targeting for professional applications.
• Durability: Shockproof up to 1200g, IP67 waterproof rating, operating temperature -30℃ to +60℃ ensures reliable use in harsh environments.
• Optical Performance: Ultra-high transmittance reflex lenses (96%) with anti-reflex, fully multi-coated surfaces for clear, bright targeting.
• Compact & Lightweight: 168.8 g, dimensions 63.6×42.8×65 mm, ideal for lightweight tactical setups.
• User-Friendly Features: Shake Awake for instant-on functionality, 12 brightness levels including NV settings for tactical versatility.
• Long Battery Life: Up to 400 hours on highest setting; up to 50,000 hours on lower settings for extended operations.

Suitable Application Scenarios

Tactical Operations & Law Enforcement: High precision targeting with fast acquisition for professional and duty firearms.

Hunting & Outdoor Adventures: Reliable in extreme weather and outdoor conditions, providing clear sight picture for short- to mid-range hunting.

Competitive & Recreational Shooting: Designed for dynamic shooting competitions and recreational use requiring durability and customizable brightness.

Customizable Features

• Reticle: 2 MOA dot with 12 brightness levels (including 2 NV modes)
• Mounting & Housing: Compatible with standard Picatinny or Weaver rails; anodized dark graphite grey finish can be customized
• Battery & Operation: CR2032 3V with optional extended life modes; Shake Awake function configurable for client needs

Parameters

Product Code	HUQ1222TR
Magnification Stated	1X
Exit Pupil Diameter	22
Eye Relief	Unlimited
Parallax Setting	100 YDS / 1′
Light Source	Chip
Wavelength	650
Click Value (1 Click)	1/2 MOA
Dot Size	2 MOA
Windage Elevation (Up Down)	〉140 MOA
Windage Elevation (Right Left)	〉140 MOA
Gear	2 (NV) + 10
Shake Awake	YES
Battery Installation	Knob installation
Reflex Lenses	Ultra-high transmittance 96% medium reflection
Coating	Anti Reflex coating, all surfaces Fully Multi-layer coating
Surface Finish	Hard Anodized, Dark Graphite Grey, matte
Housing Material	Aircraft Grade Aluminum 6061T6
Battery	CR2032 3V
Battery Life	Up to 400 hours on highest setting. Up to 50,000 hours on lower settings.
Water Proof	IP67
Shock Proof	Acceleration 1200g With 3.8HZ And 100 times
Working Temperature	-30℃ to +60℃ (-86℉ to +140℉)
Length (mm/inch)	63.6 mm (2.5 in)
Width (mm/inch)	42.8 mm (1.7 in)
Height (mm/inch)	65 mm (2.56 in)
Weight (g/oz)	168.8 g (5.95 oz)
Individually Packaged	Plastic box
Quantity per Carton	50
Carton Volume	48.5 × 26 × 32 cm
Carton Weight	14.8 kg
Carton Size	49.5 × 27 × 36 cm
