OVERVIEW

Key Advantages and Product Features

• 1X-10X magnification for close-range speed and extended mid-range precision
• FFP first focal plane design with special tactical MOA reticle
• 24 mm objective lens with broadband multi-layer green coating
• Red illumination with 6 brightness levels and CR2032 battery
• 30 mm tube diameter for mainstream mounting compatibility
• 90-98 mm eye relief for comfortable shooting positions
• Wide field of view: 108.1 ft at 1X / 11.6 ft at 10X @100 yds
• ±60 MOA windage/elevation range, 1/2 MOA click value
• 30 MOA adjustment per revolution with cap turret design
• 6061-T6 aluminum alloy, matte black finish, one-piece tube
• 1200G shock-proof, nitrogen-filled, fog-proof, and IPX5 waterproof
• Built-in quick zoom lever and fast focus eyepiece for faster operation

Application Scenarios:

Close-to-Mid Range Tactical Shooting

At 1X, the scope supports fast target acquisition and wide awareness. At 10X, it provides more detail for longer mid-range shots.

AR Rifle and Patrol Rifle Optics

With a 30 mm tube, 284 mm length, 540 g weight, and quick zoom lever, this LPVO fits modern AR platform rifles and patrol-style rifle setups.

3-Gun Competition and Dynamic Shooting

The 1-10X magnification range helps shooters transition quickly between close targets and longer-distance stages, while the fast focus eyepiece supports quick sight adjustment.

Hunting and Field Use

The red illumination, IPX5 waterproof rating, fog-proof structure, and shock-proof body make it suitable for hog hunting, driven hunting, and outdoor field shooting.

Customizable Features

• Logo Branding Supports private label LPVO product lines
• Reticle Design Tactical MOA reticle can be adjusted for hunting, tactical, or competition use
• Packaging Retail box, neutral box, or customized brand packaging
• Accessories Quick zoom lever, lens caps, cleaning cloth, mounts, or battery accessories
• Manual Language English and multi-language manuals for global distribution
• OEM/ODM Support Suitable for customized LPVO scope projects

Parameters

Product Code	BEM1-10X24IR FFP
Magnification	1X – 10X
Weight	540 g
Length	284 mm
Objective Lens Diameter	24 mm
Eye Relief	90 – 98 mm
Tube Diameter	30 mm
Electronic Lighting	Red light
Field Of View @100yds	1X: 108.1 ft; 10X: 11.6 ft (Angle: 1X: 20.6°, 10X: 2.21°)
Exit Pupil Diameter	1X: φ8.4 mm; 10X: φ2.3 mm
Reticle	Special tactical MOA reticle
Coating	Broadband multi-layer green coating
Elevation Adjustment Range	±60 MOA, 1 Click = 1/2 MOA
Windage Adjustment Range	±60 MOA, 1 Click = 1/2 MOA
Shock-Proof	Yes (1200G)
One-piece Tube	Yes
Diopter Adjustable	Yes
Nitrogen Filled / Fog Proof / Waterproof	Yes (IPX5)
Focal Plane	FFP (First Focal Plane)
Material	6061-T6 Aluminum Alloy
Surface Treatment	Matte Black Finish
Battery	CR2032
Illumination Settings	1 ON/OFF + 6 brightness levels
Adjustment Per Revolution	30 MOA
Turret Type	Cap Turret
Quick Zoom Lever	Built-in / Included
Eyepiece	Fast Focus Eyepiece
