OVERVIEW

Key Features & Advantages

Photo & Video Recording

• Captures 20MP / 16MP / 12MP photos and records 1080P / 720P / WVGA video
• Suitable for general outdoor monitoring and wildlife documentation
• H.264 compression supported for efficient storage and playback

Basic Infrared Night Vision

• Equipped with 2 pcs 850nm IR LEDs, covering up to 20 meters
• Ideal for low-light or nighttime activity detection
• Great for detecting garden intruders, nocturnal animals, or pests

Fast Response

• Trigger speed: 0.3 seconds, with main PIR angle of 60°
• Detects motion reliably while minimizing false triggers in tight spaces

Local Storage and Simple Deployment

• Supports Micro SD cards up to 32GB (not included)
• No wireless setup or app pairing—just insert card and power on
• Operates on 4×AA batteries or 6V 1A external DC power

Compact, Weatherproof, and Long-Lasting

• IP65 waterproof rating protects from dust, rain, and temperature extremes
• Runs for up to 6 months in standby
• Pocket-size housing (105×85×45 mm) and lightweight (0.18 kg) for flexible mounting

Application Scenarios

In backyard birding or school nature studies, this model provides simple, reliable image and video capture with night vision and quick setup.

For garden or poultry yard protection, the infrared sensor and weather-resistant housing help identify nocturnal visitors or intrusions.

In hiking trails or seasonal camps, its small size and long standby time make it a set-and-forget solution.

Customization Options

• OEM logo on camera housing and packaging
• Bundle options: pre-installed SD card, AA batteries, user manual in local language
• Custom startup settings and private label packaging for retail or educational markets
• MOQ supported for home security resellers, outdoor brands, and school supply distributors.

Parameters

Product Code	MiNi600
Sensor	5.0 Mega Pixels CMOS
Lens	FOV=90 with Auto IR Filter
PIR Sensing Angle	Main PIR 60°
Photo Resolution	20MP / 16MP / 12MP
Video Resolution	1080P, 720P, WVGA
Memory	Micro SD Card up to 32GB
Night Vision Range	20 Meters with 2pcs 850nm IR LEDs
Triggering Time	0.3 Second
Screen	/
Standby Time	Approx. 6 months
Operating Temperature	-20℃ to +60℃
H.264 Support	Yes
Power Supply	4×AA or external power 6V 1A DC
Language	English
Waterproof	IP65
Unit Dimensions	105×85×45 mm
Unit Weight	0.18 kg/pc
Box Dimensions	125×111×83 mm
Box Weight	0.38 kg/pc
Packing Quantity	21 pcs/ctn
Carton Dimensions	390×350×285 mm
Carton Weight	6.5 kg/ctn
