3–9x32mm Short Range Rifle Scope SHM3-9×32
Designed for hunters, law enforcement, and shooting sports professionals seeking reliable target acquisition at short to mid ranges, this scope offers 3–9x magnification with a compact 32mm objective lens for excellent maneuverability and speed. The fully multi-coated lens ensures clear images in various lighting conditions, ideal for brush hunting and tactical use.
OVERVIEW
Key Advantages and Features
- 3X–9X variable magnification: Flexibility for both fast acquisition and zoomed-in accuracy.
- Compact 32mm objective lens: Maintains a lightweight profile for short-barreled rifles or carbines.
- ±2D diopter range: Adapts to a range of vision corrections for shooter comfort.
- 80mm eye relief: Reduces risk of recoil-related injuries.
- Wide FOV: 42.4ft at 100 yards (low power) improves situational awareness; 14.1ft at max magnification.
- Durability: Waterproof, nitrogen-sealed, and shockproof—built for real outdoor abuse.
- FMC coated optics: Ensures sharp, high-contrast images with minimal glare.
- Temperature Tolerance: Operates reliably from –5°C to +40°C.
Application Scenarios:
Perfectly suited for dense woodland hunts, urban tactical training, and shooting ranges, this model supports precision targeting up to 100 yards with features like 0.25 MOA click adjustments and ±60 MOA total travel. It is optimized for shooters who require fast target transition and consistent accuracy under real-world field conditions.
Customizable for Your Brand
Logo and firmware customization available
OEM/ODM support with low MOQ
Custom language interface and startup screens
Customizable Features
- Available for OEM customization including:
- Reticle style (Duplex/Mil-Dot)
- Laser logo engraving
- Packaging design
- Tube diameter/tactical turret options
- Minimum order quantities and lead times apply—contact us to customize your scope.
Parameters
| Product Code | SHM3-9×32 |
| Magnification (Low to High) | 3X to 9X |
| Clear Aperture (Objective Lens Diameter) | 32mm |
| Eyepiece Field of View | 23 |
| Diopter Range | ±2 |
| Eye Relief | 80mm |
| Tube Diameter | 25.4mm |
| Klick Value (MOA) | 0.25 per click |
| Total Travel Elevation (100 yards) | ≥ 60 MOA |
| Total Travel Windage (100 yards) | ≥ 60 MOA |
| Parallax Compensation | 100 yards |
| Fast Focus Eyepiece | No |
| Sealing Gas (Nitrogen) | Yes |
| Clear Aperture at Min Magnification (Low Power) | 28.8mm |
| Clear Aperture at Max Magnification (High Power) | 32mm |
| Effective Exit Pupil Diameter at Min Magnification | 9.60mm |
| Effective Exit Pupil Diameter at Max Magnification | 3.56mm |
| Maximum Resolution (Arc Seconds) at Min Magnification | 6 |
| Maximum Resolution (Arc Seconds) at Max Magnification | 6 |
| Operating Temperature Range | -5°C to +40°C |
| Storage Temperature Range | 5°C to +20°C |
| Dioptric Compensation Range | ±2 Dpt |
| Permissible Backlash for Dioptric Compensation | <0.25 Dpt |
| Objective Field of View at Min Magnification (ft @100 yards) | 42.4ft |
| Objective Field of View at Max Magnification (ft @100 yards) | 14.1ft |
| Change of Impact Point After Magnification Adjustment (MOA) | 1 MOA |
| Reticle Straightening | ±2° |
| Coating | FMC (Fully Multi-Coated) |
Optimize your gear—your target deserves precision.
Contact us now to request bulk pricing or discuss your OEM customization needs for short range rifle scopes.
