OVERVIEW

Key Advantages and Features

• Optical Performance: 7× magnification, 50 mm objective lens, FMC-coated BAK4 prisms, ≤4” resolution for crisp, bright images.
• Wide Field of View: 7.5° / 393 ft @1000 yds (131 m @1000 m) for situational awareness.
• Durable & Rugged: Aluminum-magnesium alloy body, shockproof up to 2 m, waterproof up to 1.5 m for 30 min, nitrogen-filled for fogproof performance.
• User Comfort: 23 mm eye relief, fold-down eyecups, and adjustable interpupillary distance (56–74 mm).
• All-Weather Reliability: Operates in -40°C to 70°C for extreme environments.
• Portable & Ready-to-Use: Includes pouch, strap, and cleaning cloth; compact size 202 × 215 mm.

Application Scenarios

Wildlife Observation & Birdwatching: High-resolution optics with 131 m / 1000 m field coverage for detailed observation of animals and birds.

Hunting & Outdoor Adventures: Shockproof up to 2 m and all-weather performance ensure reliability during hunting or hiking in rugged terrain.

Marine & Boating Activities: Wide field of view and bright 50 mm objective lenses enhance situational awareness on boats or near water.

Customizable Features

• Accessories: Pouch, strap, and cleaning cloth included; optional custom branding available
• Focus System: Individual eyepiece focusing, adjustable interpupillary distance (56–74 mm)
• Protective Features: Nitrogen-filled waterproof housing with shockproof tolerance; optional extended temperature range customization

Parameters

Product Code	XURP7506
MODELS	7X50
Focus system	Individual
Magnification	7x
OBJ.LENS DIA.	Φ50mm
TYPE OF PRISM	Porro/BAK4
Number of Elements & Group	7 elements/5 groups
Coating	FMC
Field of View\ Angle	7.5°
M / 1000 M	131M
FT / 1000 Yds	393FT
Exit-pupil Diameter	Φ7.14MM
Eye Relief	23MM
Interpupillary Distance	56MM ～74MM
resolution	≤4”
Near Focus	5M
all-weather	yes
Shock-Proof	2M/6side
Waterproof	1.5m / 30min
Nitrogen Filled	yes
Eyecups System	Fold Down
Low Temperature	40°
High Temperature	70°
Material	Aluminum-magnesium alloy
Pouch	yes
Cleaning Cloth	yes
Strap	yes
Silica Gel	No
Product Dimensions	202mmX215mm
Qty per Carton	6pcs
