Large Viewing Window Open Emitter Pistol Red Dot Sight XIX1401OR
Red dot sight with 75g lightweight design, for pistols, ideal for hunting and tactical shooting
The XIX1401OR Reflex Red Dot Sight delivers a perfect balance of compact design, precision engineering, and advanced optical performance. Built for users who value speed, clarity, and accuracy, it offers reliable target acquisition and dependable performance across a wide range of outdoor conditions.
OVERVIEW
Key Advantages and Features
Compact Yet Powerful Design
With dimensions of 44.5 × 32.6 × 40 mm and a lightweight 75 g build, this sight provides effortless handling and stability without compromising durability.
High-Definition Optics
Equipped with ultra-high-transmittance (95%) optical components and a multi-layer magenta coating, the XIX1401OR delivers bright, crisp, and true-to-life visuals with minimal distortion.
Dual Reticle Precision
Combines a 2 MOA Dot and 32 MOA Circle reticle, enabling quick, intuitive alignment for various environments and distances.
Superior Accuracy
Features ±0.5 MOA parallax and a 1-click = 1 MOA adjustment system with clear tactile feedback for precise zeroing and confident control.
Constructed with quenched Mn steel for long-lasting adjustment stability and precision performance.
Smart Power Efficiency
Designed for extended use with 700 hours of standby time and auto power-off after 2 hours of inactivity, ensuring longer operation and reduced maintenance.
Wide Adjustment Range
Offers an effective adjustment range of ±75 MOA, providing the flexibility needed for fine-tuning and consistent accuracy in changing conditions.
Reliable Hardware Construction
Engineered with Grade 12.9 mounting bolts and screws, ensuring robust attachment and enduring mechanical strength.
Premium Optical Protection
The multi-layer magenta coating enhances brightness and contrast while protecting the lens from glare and minor surface abrasions.
Professional Packaging
Each sight is securely packaged in a durable plastic box, with 50 units per carton (carton size: 480 × 270 × 340 mm, total weight: 9.7 kg).
Customizable for Your Brand
Logo and firmware customization available
OEM/ODM support with low MOQ
Custom language interface and startup screens
Parameters
| Product Code | XIX1401OR |
| Product Size | 44.5 × 32.6 × 40 mm |
| Window Size | 24.2 × 17.6 mm |
| Weight | 75 g |
| Optical Components | Ultra-high-transmittance 95% medium reflection |
| Coating | Ultra-high-transmittance multi-layer magenta coating |
| Power Consumption (Standby) | 700 h / Auto power-off after 2 h idle |
| Reticle Size | 2 MOA Dot + 32 MOA Circle |
| Zeroing Distance | 15 m |
| Parallax | ±0.5 MOA |
| Click Sound | Clear tactile feedback per detent |
| Adjustment Mechanism | Quenched Mn steel |
| Click Value | 1 click = 1 MOA |
| Effective Adjustment Range | ±75 MOA |
| Mounting Bolt | Grade 12.9 |
| Screws (Body to Mount) | Grade 12.9 |
| Individual Packaging | Plastic box |
| Carton Capacity | 50 units |
| Carton Weight | 9.7 kg |
| Carton Size | 480 × 270 × 340 mm |
