High-sensitivity Thermal Imaging Binoculars ZHB319
These advanced Thermal Imaging Binoculars are engineered for professional hunters, law enforcement teams, and outdoor surveillance units requiring fast target detection, even in complete darkness. Featuring a 384×288 VOx uncooled thermal sensor, NETD ≤30mk, and two objective lens configurations (19 mm / 25 mm), they deliver high-clarity thermal imagery with enhanced detection capabilities out to 1500 meters.
OVERVIEW
Product Features and Benefits
- VOx uncooled thermal sensor (384×288 @ 12μm pixel pitch)
- High thermal sensitivity (NETD ≤30mk) enables fine detail detection in low thermal contrast
- Dual lens configurations:
19 mm lens: 1.4X–5.6X magnification, 1200 m detection range
25 mm lens: 1.8X–7.2X magnification, 1500 m detection range - OLED display (640×400) for crisp thermal imagery with intuitive palette switching
- Multiple thermal palettes: White Hot, Black Hot, Ironbow, Glowbow, Sepia, Red Hot, Green Hot
- Wi-Fi enabled (802.11b/g/n, 2.4GHz) for image sharing and mobile preview within 10 m
- Built-in 32 GB storage, records video (MP4) and photo (JPG) at 512×384 resolution
- 18650 battery-powered (3200mAh) for ≥6 hours runtime, with USB charging support
- IP67 waterproof rating, shock-resistant, and temperature-resistant from -25°C to +50°C
- Compact and lightweight: 510 g / 530 g with 165 mm / 170 mm body length
Customizable for Your Brand
Logo and firmware customization available
OEM/ODM support with low MOQ
Custom language interface and startup screens
Ideal Applications
Perfect for nighttime hunting, border patrol, search and rescue missions, and tactical surveillance, these binoculars offer 1.4X to 7.2X optical zoom, ultra-clear OLED displays, and color palette options including White Hot, Black Hot, Ironbow, Glowbow, and Red/Green Hot. With IP67 waterproofing and 6+ hour battery life, they’re ready for use in harsh field environments from -25°C to +50°C.
Customization Options
Supports OEM logo laser engraving, lens configuration selection (19 mm or 25 mm), and interface localization (languages, firmware branding). Flexible low MOQs available for defense contractors, tactical brands, or outdoor optics distributors seeking private-label thermal devices.
Parameters
| Thormal Monocular | |||
| Product Code | ZHB319 | ZHB325 | |
| Detector Specifications | Detector Type | VOx Uncooled | |
| Detector Resolution, pixels | 384×288 | ||
| Detector Pixel Size, μm | 12μm | ||
| NETD, mk | ≤30mk | ||
| Frame Rate, Hz | 50Hz | ||
| Optical Specifications | Objective Lens, mm | 19mm | 25mm |
| Field of View (H×V), º | 13.8°×10.4° | 10.5°×7.9° | |
| Optical Magnification, × | 1.4X~5.6X | 1.8X~7.2X | |
| Exit pupil Diameter, mm | 18mm | ||
| Diopter, D | ，-7D~+2D | ||
| Display Specifications | Type | OLED | |
| Resolution | 640*400 | ||
| Palette | White Hot/Black Hot/Ironbow/Glowbow/Sepia/ | ||
| Red Hot/Green Hot | |||
| Detection Range, m | Detection Range（human height，1.8m） | 1200m | 1500m |
| Video Storage | Photo / Video Resolution | 512*384 | |
| Photo / Video Format | mp4/jpg | ||
| Built-in storage | 32GB | ||
| Connection | Wi-Fi | Wi-Fi | |
| Wireless standard | 802.11b/g/n | ||
| Wireless Wide Band | 2.4GHz | ||
| Connection distance | ≤10m | ||
| Power | Output voltage | 3~4.2V | |
| Battery | 18650 Batteryâ…¹1 | ||
| Battery Capacity | 3200mAh | ||
| Max. Operating Time (22ºC), h* | ≥6hrs. | ||
| External power supply voltage | 5V | ||
| Charging time | ≈3hrs | ||
| Charging Temperature | 0~45℃ | ||
| Environmental Characteristics | IP rating | IP67 | |
| Operating Temperature, °C | ，-25℃～+50℃ | ||
| Storage Temperature, °C | ，-40℃～+60℃ | ||
| Physical Characteristics | Weight , g | 510g | 530g |
| Dimension, mm | 165mm | 170mm | |
Let’s Collaborate
Looking to offer advanced thermal imaging solutions for night operations, hunting, or security?
Contact us today for OEM options, pricing, and sample availability.
