Professional-grade Long-Range Zoom Monoculars HUYA82440
These professional-grade Monoculars, available in 8–24×40 and 11–33×56 configurations, are built for users who demand zoom versatility, weather resistance, and optical clarity in compact form. Whether scanning wide terrain or honing in on distant targets, these models are ideal for wildlife professionals, tactical users, eco-tour operators, and long-distance observers who operate in varied outdoor conditions.
OVERVIEW
Key Advantages and Features
- Precision Zoom Flexibility: Adjustable magnification allows users to easily transition from wide-angle terrain scanning to focused long-range targeting. With up to 33x power, users can track movement across vast distances without switching devices.
- Superior Visual Performance: Each model features multi-coated lenses and a BK7 roof prism system, which enhance light transmission, reduce glare, and improve color contrast. The optical configuration ensures sharp imagery, even at maximum zoom.
- Built for Harsh Environments: Both models are nitrogen-filled and waterproof, providing fogproof operation and IPX-rated weather protection. They’re ideal for unpredictable field conditions—whether in rainforests, deserts, or coastal zones.
- Comfortable and User-Friendly: Designed for field comfort, each monocular includes twist-up eyecups and generous eye relief (up to 15.5 mm), accommodating eyeglass wearers and reducing strain during prolonged observation.
- Lightweight and Packable: Despite their optical power, both units maintain a compact footprint and are backpack-compatible, weighing less than 1 kg and requiring minimal setup—perfect for stealth use or ultralight field kits.
Application Scenarios
- The 8–24×40 model strikes a balance between portability and performance, making it a go-to tool for day hikers, birders, and mobile field researchers needing adaptable magnification.
- The 11–33×56 variant delivers powerful reach and sharper detail, perfect for coastal surveillance, open-range wildlife tracking, or mountainous terrain scouting.
- Both units are optimized for quick deployment, on-the-go use, and extended observation sessions.
Customizable for Your Brand
Logo and firmware customization available
OEM/ODM support with low MOQ
Custom language interface and startup screens
Customizable Features
- OEM logo engraving on housing
- Custom exterior finishes (color/texture)
- Branded packaging design for retail or tactical applications
- MOQ flexibility for distributors of outdoor gear, law enforcement optics, or adventure sports equipment
Parameters
| Product Code | HUYA82440 | HUYA113356 |
| POWER | 8X-24X | 11X-33X |
| OBJ. LENS DIA. | 40MM | 56MM |
| ocular lens Dia. | 22 | 19 |
| TYPE OF PRISM | ROOF/Bk7 | ROOF/Bk7 |
| PRISM COATING | YES | YES |
| NUMBER OF LENS | 8Pcs/6Groups | 8Pcs/6Groups |
| LENS COATING | Multi Coated | Multi Coated |
| FOCUSING LENS | Int. | Int. |
| EXIT PUPIL DIAMETER | 5.-1.65MM | 5-1.65MM |
| EXIT PUPIL DIST. | 15.5-12MM | 15-12MM |
| FIELD OF VIEW | 4.5-2.2° | 3.2-1.6° |
| FIELD OF VIEW | 235.5-115.5Ft / 1000Yds | 168-84Ft / 1000Yds |
| FIELD OF VIEW | 78.5-38.5M / 1000M | 56-28M / 1000M |
| RESOLUTION | 4.5 | 3.5 |
| MIN. FOCAL LENGTH | 4M | 5M |
| ZOOM SYSTEM | YES | YES |
| WEATHER PROOF | YES | YES |
| WATER PROOF | YES | YES |
| WATER RESIST | YES | YES |
| NITROGEN FILLED | YES | YES |
| FOLDING EYECUPS | Twist-up eyecup | Twist-up eyecup |
| UNIT DIMENSION | 160x78x59.5 | 198x84x70 |
