OVERVIEW

Key Advantages and Features

• Versatile 1.5X–5X Magnification: Offers flexibility for both snapshot speed at low power and precise target hold at higher power.
• Extra-Wide Objective FOV: Up to 84.9 ft at 100 yards (low power), ensuring fast acquisition in dynamic shooting environments.
• Stable Optical Resolution: Maintains 6 arc seconds across magnification levels for sharp, distortion-free imaging.
• Advanced Optical Coating: FMC (Fully Multi-Coated) lenses enhance brightness, color fidelity, and contrast in all light conditions.
• Durable Construction: Shockproof, waterproof, and nitrogen-sealed, ensuring performance in extreme temperatures from -5°C to +40°C.
• Precision Adjustment: 0.5 MOA click value with a broad elevation and windage travel of ≥60 MOA.
• Consistent Eye Relief: Generous 96m

Application Scenarios:

• Perfectly suited for close-quarters engagement and transitional shooting environments, this scope supports applications such as tactical team deployment, driven hunts, hog and coyote control, or high-mobility 3-gun competitions.
• Whether mounted on AR platforms or modern sporting rifles, it ensures quick acquisition and repeatable accuracy.

Customizable Features

OEM customization available for turret design, reticle options (including illuminated or etched variants), and coating finishes. Private-label branding, packaging customization, and bulk order support included.

Parameters

Product Code	SHM1.5-5×32
Magnification (Low Power)	1.5X
Magnification (High Power)	5X
Clear Aperture (Objective Lens Diameter)	32mm
Eyepiece Field of View	23
Diopter Range	±2
Eye Relief	96mm
Tube Diameter	30mm
Click Value for E/W Adjustment	0.5 MOA
Total Travel Elevation Adjustment (at 100 yards)	≥ 60 MOA
Total Travel Windage Adjustment (at 100 yards)	≥ 60 MOA
Parallax Compensation	50 yards
Fast Focus Eyepiece	Yes
Sealing Gas	Nitrogen
Clear Aperture at Minimum Magnification (Low Power)	28.5mm
Clear Aperture at Maximum Magnification (High Power)	32mm
Effective Exit Pupil Diameter (Low Power)	18.99mm (±3%)
Effective Exit Pupil Diameter (High Power)	6.40mm (±3%)
Resolution (Low Power)	6 arc seconds
Resolution (High Power)	6 arc seconds
Operating Temperature Range	-5°C to +40°C
Storage Temperature	5°C to +20°C
Dioptric Compensation Range	±2 dpt
Permissible Backlash in Dioptric Compensation	<0.25 dpt
Objective Field of View (Low Power, @ 100 yards)	84.9ft
Objective Field of View (High Power, @ 100 yards)	25.5ft
Impact Point Change After Magnification Adjustment	1 MOA
Reticle Tilt	±2°
Coating	FMC (Fully Multi-Coated)
