Rangefinder Binoculars | 10×50 Laser Rangefinding Binoculars with 2000m Range, BAK4 Prisms, FMC Optics and Angle Measurement YUY10501R
The YUY10501R 10X52 Laser Rangefinder Binoculars are positioned as high-performance observation and distance-measurement optics for hunting brands, wildlife observation equipment suppliers, outdoor optics distributors, and private label rangefinder binocular manufacturers.
Unlike conventional binoculars designed solely for visual observation, the YUY10501R integrates a 905nm Class 1 laser rangefinder with a maximum ranging capability of 2000 meters, allowing users to observe distant subjects and obtain distance information through a single optical device.
The combination of 10X magnification, 52mm objective lenses, BAK4 roof prisms, fully multi-coated glass optics, and an integrated LCD ranging display provides a versatile solution for customers who require both optical observation and laser measurement.
With nitrogen-filled construction, outdoor water resistance, and a comfortable 17.9mm eye relief, this model is particularly suitable for mid-to-high-end hunting optics collections, professional outdoor observation equipment, and OEM laser rangefinder binocular programs.
OVERVIEW
Key Advantages and Features
Integrated 2000m Laser Rangefinder
The built-in 905nm Class 1 laser rangefinder offers a maximum measuring range of 2000 meters, enabling users to observe and measure distant subjects through one device.
The integrated ranging function reduces the need to carry separate optical and distance-measurement equipment. Actual ranging performance depends on target reflectivity, size, and environmental conditions.
10X52 Optical System with BAK4 Roof Prisms
The 10X magnification provides detailed observation of distant subjects, while the 52mm objective lenses offer substantial light-gathering potential.
BAK4 roof prisms and fully multi-coated glass optics help deliver a practical balance of image clarity, brightness, and streamlined binocular construction.
Fully Multi-Coated Glass Optics
The broadband multi-layer coatings help minimize reflections at optical surfaces and support effective light transmission.
With a specified overall light transmission of 80%, the YUY10501R offers an optical configuration suitable for outdoor observation across a variety of daylight conditions.
Integrated LCD Ranging Display
The high-transmission black LCD allows users to view distance measurements within the binoculars, combining observation and measurement into a convenient operating experience.
The integrated angle measurement function provides additional field information for outdoor users.
Comfortable and Adjustable Viewing
The 17.9mm eye relief, center focus system, right-eye diopter adjustment, and adjustable interpupillary distance allow users to adapt the binoculars to individual viewing requirements.
These features support comfortable observation during hunting, wildlife monitoring, and extended outdoor viewing sessions.
Weather-Resistant Outdoor Construction
The nitrogen-filled design helps prevent internal fogging caused by environmental temperature changes, while the specified water-resistant construction supports outdoor operation.
The PPS housing provides a lightweight engineering-plastic structural platform suitable for portable observation equipment.
Application Scenarios
Long-Range Hunting and Distance Measurement
The YUY10501R is designed for hunters who need to observe wildlife and measure distances across open fields, grasslands, and mountainous terrain.
Its 10X optical magnification supports detailed observation, while the integrated laser rangefinder helps users obtain distance information without switching between separate binoculars and a handheld rangefinder.
The angle measurement function adds useful information when observing subjects on elevated or sloping terrain.
Wildlife Observation and Field Monitoring
The 52mm objective lenses and BAK4 roof prism system make these binoculars suitable for observing distant wildlife in nature reserves, wetlands, and open landscapes.
The built-in distance measurement function provides additional context when monitoring animal positions, observing habitats, or documenting outdoor field activities.
Mountain Observation and Outdoor Exploration
The YUY10501R is suitable for observing distant ridgelines, landmarks, valleys, and terrain features during outdoor exploration.
Its integrated rangefinder and ±90° angle measurement capability provide practical information for users assessing distances and terrain from a fixed observation position.
Nitrogen-filled construction and outdoor moisture protection further support use in changing environmental conditions.
Outdoor Observation and Specialist Retail Markets
For users who frequently observe distant landscapes, natural features, or fixed objects, the YUY10501R combines binocular viewing with direct distance measurement.
This dual-function configuration makes it a suitable product for specialist outdoor retailers seeking to offer more advanced observation equipment than conventional fixed-magnification binoculars.
Customizable for Your Brand
Logo and firmware customization available
OEM/ODM support with low MOQ
Custom language interface and startup screens
Customizable Features
| Customizable Part | B2B Value |
| Logo Branding | Private label identification for hunting and outdoor optics brands |
| Housing Appearance | Customized exterior colors, finishes, and branding details |
| Optical Configuration | Coating and optical configuration adjustments subject to engineering feasibility |
| Ranging Interface | Display and software customization options subject to firmware compatibility |
| Packaging & Accessories | Branded carrying cases, straps, manuals, and retail packaging |
| OEM/ODM Development | Product configuration and brand differentiation based on MOQ and technical requirements |
Parameters
| Product Code | YUY10501R |
| Magnification | 10X |
| Body Material | PPS |
| Objective Lens Diameter | Φ52mm |
| Eyepiece Diameter | Φ26mm |
| Exit Pupil Diameter | Φ5mm |
| Eye Relief | 17.9mm |
| Field of View | 5.6° |
| Field of View at 1000m | 98m |
| Field of View at 1000yds | 294ft |
| Near Focus | 3.5m |
| Light Transmission | 80% |
| Resolution | 5.33″ |
| Diopter System | Right Diopter Ring |
| Interpupillary Distance Adjustment | 56 ~ 74mm |
| Focus System | Center Focus |
| Focusing Lens | Eyepiece Focus |
| Diopter Compensation | -4 ~ +4 Diopter |
| Focusing Adjustment Range | -4 ~ +8 Diopter |
| Prism System | Roof Prism |
| Prism Material | BAK4 |
| Objective Lens Construction | 3E2G (3 Elements, 2 Groups) |
| Eyepiece Construction | 3E2G (3 Elements, 2 Groups) |
| Lens Type | Spherical Lens |
| Optical Material | All Optical Glass |
| Lens Coating | Fully Multi-coated (Broadband Green Film) |
| Coating Specification | 420-905nm, R < 0.5% (AVG) |
| Incident Surface Coating | Fully Multi-coated (905nm) |
| Waterproof / Fogproof | Yes |
| Gas Filled | Nitrogen |
| Laser Wavelength | 905nm |
| Laser Power | <1mW |
| Laser Class | Class 1 |
| Ranging Display | Black High-transmission LCD |
| Ranging Accuracy | ±0.5m + 1% |
| Angle Measurement | ±90° |
| Waterproof Rating | IP65 / IP67 |
| Dimensions (L×W×H) | 146 × 111 × 51mm |
| Weight | 780g / 800g |
| Battery | CR2 |
| Operating Temperature | -20°C ~ +50°C |
| Ranging Range | 2000m |
Let’s Work Together
Contact FORESEEN OPTICS to discuss wholesale pricing, MOQ, samples, and customized 10X52 laser rangefinder binocular solutions for your brand.
