OVERVIEW

Key Advantages and Features

• Wide Zoom Range (3x–9x): Adapt to close-range movement or distant shots without swapping optics.
• Large Objective Lens (42mm): Enhances image brightness, even in dawn or dusk lighting conditions.
• Comfortable Eye Relief (102–80mm): Ensures safe, full-view shooting across various rifle platforms.
• Precision Engineering: 25.4mm one-piece tube construction for greater alignment integrity and recoil durability.
• Wide Field of View: 6.4°–2.1° field of view at 100 yards—ideal for scanning and tracking fast-moving targets.
• Laser Targeting Enhancement: Built-in laser (customizable wavelength & mode) accelerates your target lock-in and supports low-light accuracy.

Application Scenarios:

Perfect for medium-range hunting with rifles (e.g., 3-9x laser scopes for deer hunting), tactical range shooting (e.g., adjustable magnification laser rifle scopes for AR-15), and pest control across open fields. The generous eye relief (102–80mm) enhances safety with high-recoil calibers, while the wide 6.4°–2.1° FOV ensures fast target acquisition in dynamic environments.

Customizable Features

OEM & ODM support available for reticle patterns, logo engraving, turret design, and optical coatings. Compatible with illuminated or etched reticles, different laser wavelengths (red/green), and can be bundled with Picatinny/Weaver mounts or tactical rings. MOQ applies—consult us for tailored solutions.

Parameters

Product Code	HUQ3-9X42E/HUQ3-9X42EC
Specification Model	3-9X42E/EC
Magnification	3X–9X
Objective Diameter	42 mm
Exit Pupil Diameter	14–4.67 mm
Length	322 mm
Tube Diameter	25.4 mm
Eye Relief	102–80 mm
Field of View (@100 yds)	6.4°–2.1°
