OVERVIEW

Key Advantages and Features

• 1x True Magnification with Unlimited Eye Relief – Provides natural target acquisition with both eyes open, improving speed and spatial awareness.
• Ultra-Wide Lens with 33×24 mm Aperture – Ensures a large field of view, ideal for fast-moving targets and situational dominance.
• 2MOA Precise Dot with 12 Brightness Levels – Crisp aiming point with 2 NV settings and 10 daylight levels, suitable for all environments.
• Motion-Activated Shake Awake Technology – Automatically powers on when moved, conserving battery without compromising readiness.
• Extreme Durability with IP67 Waterproof Rating – Tested to withstand acceleration of 1200g, operating from -30°C to +60°C. Survives impact, water immersion, and thermal shock.
• Long-Lasting CR2032 Battery Life – Runs up to 400 hours at max brightness, or up to 50,000 hours at lower settings.
• Aircraft-Grade Housing with Matte Hard Anodized Finish – Constructed from PA6 + 6061-T6 aluminum, offering tactical-grade toughness in a compact form.

Technical Specifications

• Magnification: 1x
• Lens Size: 33×24 mm
• Dot Size: 2MOA
• Click Value: 1/2 MOA
• Windage/Elevation Adjustment: >140 MOA
• Battery: CR2032 3V
• Battery Life: Up to 50,000 hrs
• Dimensions: 88 × 49 × 64 mm
• Weight: 295g / 10.4oz
• Waterproof Rating: IP67
• Mount Type: Knob top mount

Application Scenarios

Optimized for CQB (Close Quarters Battle), 3-gun competition, and rapid engagement drills, this optic performs in all lighting and weather conditions. Compatible with AR platforms, shotguns, and PCCs for both civilian and professional operators.

Customizable Features

• OEM/ODM branding available
• Multiple reticle colors and brightness gear configurations
• Optional low-profile or QD mount designs upon request

Parameters

Model	HUQ124TR
Magnification  Stated	1X
Exit  Pupil  Dia	33*24
Eye  relief	Unlimited
Parallax setting	100YDS / 1′
Light Source	Chip
Wavelength	650 /510
Click  Value  I  Click	1/2 MOA
Dot  size	2MOA
Windage  Elevation (Up Down)	〉140MOA
Windage  Elevation (Right Left)	〉140MOA
gear	2（NV）+10
shake  awake	YES
Battery installation	Knob installation
reflex  lenses	Ultra-high transmittance 96% medium reflection
Coating	Anti Reflex coating,all surfaces Fully Multi-layer coating
Surface  Finish	Hard Anodized,Dark Graphite Grey,matte
Housing Material	PA6 & Aircraft Grade Aluminum   6061T6
Battery	CR2032  3V
Battery  life	Up to 400 hours on highest setting. Up to 50,000 hours on lower settings.
Water Proof	IP67
Shock Proof	Acceleration 1200g With 3.8HZ And 100 times
Working temperature	.  -30℃ to +60℃(-86℉ to +140℉)
Length (mm)  (inch)	88mm(3.46in)
Width (mm)  (inch)	49mm(1.93in)
Height (mm)  (inch)	64mm(2.52in)
Weight (Gram) (Ounce)	295g(10.4oz)
Individually packaged	plastic box
A box of quantity	20
Volume of a box	12.9kg
weight of a box	20kg
box  size	39.5cm*32cm*41cm
