OVERVIEW

Key Features & Benefits

Full 4G LTE Remote Connectivity

• Supports FDD-LTE, TDD-LTE, WCDMA, and GSM bands for global deployment
• Remote control via SuntekCam / TCamPro app
• Live photo/video preview, clip transmission (5s–30s), and remote configuration without physical access

Ultra-Wide Detection with PIR Coverage

• Triple PIR sensors with a 120° field of view for maximum coverage
• 0.3-second trigger speed for fast-moving subjects
• Customizable working mode: 1s / 5s / 10s / 30s delay settings

Sharp Imaging with Stealth Infrared

• 30MP / 24MP / 20MP photo options
• 2K / 1080P / 720P video recording in AVI format
• Equipped with 2 low-glow IR LEDs and 3 high-power 940nm lamps for up to 20m night vision – undetectable to animals and humans

Rugged, Autonomous Field Operation

• Runs on 8×AA batteries or 12V DC input
• Up to 6-month standby time with low idle current draw (0.1A)
• Compatible with strap/tripod mounting, solar input, and TF cards up to 512GB

Data Security & Field Reliability

• Timestamp (time/date/temp) for every image/video
• 4-digit password protection for unauthorized access
• Certified IP65 waterproof, FCC, CE, RoHS, REACH, RED compliant

Application Scenarios

Wildlife researchers benefit from 30MP high-res photos, low-glow 940nm IR, and 0.3s trigger response for accurate, undisturbed monitoring in forests or nature reserves.

Remote landowners and security teams can receive 5–30s video clips or stream live footage via the SuntekCam or TCampro apps, even from remote mountain cabins or agricultural fences.

Smart parks and eco-tourism facilities use its time-lapse mode and cloud-ready transmission to automate trail monitoring and activity logging.

Customization Options

• OEM branding on casing, splash screen, and retail packaging
• Carrier-specific SIM preconfiguration
• Multilingual firmware and UI (13 languages)
• MOQ supported for system integrators, outdoor technology brands, and NGO-driven ecological initiatives.

Parameters

Product Code	HC880PRO
Image Sensor	5MP CMOS Sensor
Storage	TF card, supports up to 512GB
Lens	F=3.1; FOV=120°
Camera Size	140×96×47mm
IR Light	2 low-glow IR lamps
IR Wavelength	940nm
IR Detection Sensitivity	High/Medium
IR Detection Angle	120° (3 PIR)
IR Light Count	3 high-power IR lamps
IR Night Vision Distance	65 feet / 20 meters
Shooting Modes	Photo/Video/Photo + Video/Time-lapse
Working Mode	1/5/10/30s (adjustable)
Trigger Time	0.3s
Timer Shot	Yes
Photo Resolution	30MP / 24MP / 20MP
Continuous Shooting	3/6/9 shots selectable
Video Resolution	2K / 1080P / 720P
Video Format	AVI
Video Transmission	Yes (5s–30s clip sent via app, live video)
Timestamp	Yes, includes time, date, temperature
Timed Photo	Yes
Password	4-digit numeric password
Supported Bands	FDD-LTE: B1/B3/B5/B7/B8/B20; TDD-LTE: B38/B40/B41; WCDMA: B1/B5/B8; GSM: 900/1800
App	SuntekCam / TCampro
App Functions	Remote config, real-time photo/video preview
Interface	USB2.0 port, TF card slot, SIM card slot, 12V solar panel input
Instant Current	0.1A (instant)
Standby Time	6 months
Power Supply	8×AA 1.5V batteries or 12V/2A adapter
Mounting	Strap, tripod
Waterproof Rating	IP65
Languages	13 languages, default English
Certifications	FCC, CE, RoHS, REACH, RED
