OVERVIEW

Key Features & Benefits

📸 32MP Ultra-Clear Imaging + 4K Video – Supports 3840×2160/10fps, 20MP, 16MP, and more

🎯 82ft (25m) Trigger Distance & 0.2s Speed – Captures even fast-moving targets instantly

🌙 Starlight-Level Night Vision – 38pcs IR LEDs with 35m flash range; clear imaging in complete darkness

💾 Supports External Memory up to 512GB – TF card Class 6 and above

🕒 Programmable Time Lapse & Trigger Interval – Full control over capture behavior from 1s to 24h

🧠 Auto Image Switching & Time Stamping – Day/night color recognition, serial No., moon phase, temperature

📶 Built-in Wi-Fi Module – Easy on-site setup and media access without disturbing the camera

🔋 Power Efficient with Long Standby – Expandable to 8xAA batteries, up to 18 months standby

💦 IP66 Waterproof Housing – Resists rain, snow, dust, and harsh field conditions

🔐 Security Ready – Lockable housing with optional 4-digit password protection

🔊 Built-in Microphone and Speaker – Supports camera+video hybrid recording

🖥️ Mini USB 2.0 + TV-Out – Easy file transfer and real-time display options

Application Scenarios

Wildlife monitoring and research, offering discreet long-term recording with programmable time lapse

Game tracking in forests or farmland, with fast 0.2s trigger speed and 82ft PIR range

Remote farm or property surveillance, using Wi-Fi connection and night vision infrared coverage up to 35m

Customization Options

OEM/ODM customization available for:

• Logo branding (laser engraving or printed)
• Housing color and camouflage patterns
• Menu languages, firmware behavior, and recording logic
• Retail packaging and private label design

📩 Talk to us to tailor this trail camera to your brand or end-user market.

Parameters

Model Number		JSK-H8201
Image sensor		8Mega pixels & 2MP starlight level NIR sensor
Still image size		32MP:6480×4860;20MP:5200×3900;16MP:4608×3456;12MP:4000×3000;8M:3264×2448;5M:2592×1944;3M:2048*1536; 1M:1280*960;
Video clip		3840×2160/10fps；2688×1520/20fps；1920×1080/30fps；1280×720/60fps；1280×720/30fps；720×480/30fps; 640×480/30fps;320×240/30fps
File format		JPG/AVI
Lens angle		day：f=3.3mm; F/NO 2.0; FOV=110° ; niaght：f=4.0mm; F/NO 1.4; FOV=110° ;
LCD Display		2.4″TFT  720*320
Memory		External memory(TF card, Class 6 Above, up to 512GB)
Operation keypad		8 Keys
Wifi moudle		Yes
The number of IR lamp		38PCS
Range of IR flash		35m
Triggering distance		82ft/25m（ Below 77°F/25°C at the Normal Level）
PIR sensitivity		High/Normal/Low
PIR sensing angle		Main PIR(60° ) + side PIR=110°
Triggering time		0.2Second
Trigger interval		5sec. – 60min;Programmable
Shooting numbers		1/2/3/6/10;
Video Length		3sec-10Minutes.; Programmable
Effectiveness		Daytine:1.5m-infinitive;Night time:1.5m-20m
Camera+Video		First take Picture then Video
Time stamp		On/Off;Include serial No.,temperatureand moon phase
Time lapse		On/Off; Time Lapse Programmable
Compressed video		TL Video  Time Laps 3 Second ~ 24Hours
Endless Capture		On/Off;
Target Recording Time1		Time Laps 1 Second ~ 24Hours
Target Recording Time2		Time Laps 1 Second ~ 24Hours
Device serial No.		4 digits set by yourself
Build-in Micophone/Speaker		Yes
Auto-distinguish images		Color images in daytime/black & white night images
Automatic screen saver		Automatic screen saver in 2 minutes while no keypad controlling
TV-out		Yes
PC interface		Mini USB2.0
Power supply		4xAA;Expandable to 8xAA，external 6V power supply,at least 1.5A
Standby time		approx.18 months
Lockable		Optional
Password protection		4-Digit Numbers
Spray-water protected		Spray-water protected(IP66)
Operating temperature		-20℃ to +60℃
Storage Temperature		-30℃ to +70℃
Dimensions & Weight		approx.136*90*76mm /
