OVERVIEW

Key Advantages and Features

🔍 High-Resolution Thermal Sensors
Choose from 256×192, 384×288, or 640×512 thermal cores with 12μm pixel pitch and ultra-sensitive ≤20mK NETD, ensuring crisp thermal contrast in all weather conditions.

📺 AMOLED Display + 50Hz Frame Rate
1024×768 AMOLED with smooth refresh rate for fast target tracking and fatigue-free viewing in dynamic scenarios.

🔭 Long-Distance Detection + Laser Rangefinding
Detect human-size targets up to 2500m, with integrated 905nm laser rangefinder supporting up to 1500m accurate measurements (±1m).

🎯 Built-In Ballistic Correction
On-board ballistics algorithm adjusts aiming point based on distance for accurate first-shot impact.

🎥 Smart Recording Features

Recoil-activated video
Built-in microphone
Wi-Fi & mobile app (HuntIR)
32GB internal storage

⚙️ Rugged Tactical Construction

Lightweight magnesium alloy body
IP67-rated waterproof/dustproof
Supports up to 6000J recoil resistance
Operates between -20°C to +50°C

🔋 Flexible Power Options
Internal 3~4.2V power or USB Type-C external 5V input, with up to 8 hours operation

Application Scenarios

Optimized for diverse environments, this scope excels in:

• Night hunting in forests or wide-open plains with fast detection at up to 2500 meters
• Tactical surveillance and target acquisition, even in fog, smoke, or total darkness
• Border patrol and anti-poaching missions, with real-time video and Wi-Fi app support

Customizable Features

We support a wide range of customization to match your brand or end-user market needs:

• Logo customization (laser engraving or silk print)
• Ballistic profiles and software UI in multiple languages
• Outer housing color / finish (matte black, tan, camo, etc.)
• Packaging, accessories, and branded manuals

📩 Ask about white-label solutions or API integration for your law enforcement platform.

Parameters

Product Code	CZF-OS256	CZF-OS384	CZF-OS640
Resolution, pixel	256×192	384×288	640×518
Pixel Size, μm	12	12	12
NETD, mK	≤20	≤20	≤20
Frame Rate, Hz	50	50	50
Type	AMOLED	AMOLED	AMOLED
Resolution, pixels	1024×768	1024×768	1024×768
Size, inch	0.39	0.39	0.39
Max. recoil power on rifled weapon (Eo), Joules	6000	6000	6000
Mount	Picatinny mount	Picatinny mount	Picatinny mount
Objective Lens, mm	F25/1.0	F35/1.0	F50/1.0
Field of View, °	7.5 × 5.7	12.5 × 9.4	7.5 × 5.7
Linear Field of View (H×V), m at 100m	13.2 × 9.9	21.9 × 16.5	13.2 × 9.9
Visual Magnification, ×	3.6 ~ 14	2 ~ 8	3.5 ~ 14
Eye Relief, mm	48	48	48
Diopter Adjustment, D	-5 ~ +5	-5 ~ +5	-5 ~ +5
Exit pupil Diameter, mm	10	10	10
Detection Range, m (Target size:1.7m×0.5m, P(n)=99%)	1500	1800	2500
Max Operating°C), hTime(t=22 ★	8	8	8
Service Voltage, V	3~4.2	3~4.2	3~4.2
External Power Supply, V	5 (Type c)	5 (Type c)	5 (Type c)
Safety Class for Laser	Class 1	Class 1	Class 1
Wavekength	905nm	905nm	905nm
Max. Measuring Range	700m	1000nm	1500m
Measurement Accuracy	士1m	士1m	士1m
Min. Measuring Range	10m	10m	10m
Ballistic Correction	YES	YES	YES
Wi-Fi/APP	Support(HuntlR)	Support(HuntlR)	Support(HuntlR)
Photo /Video Recorder	support	support	support
Recoil activated video	support	support	support
MIC	support	support	support
IP Rating	IP67	IP67	IP67
Memory Capacity, GB	32	32	32
Operating Temperature,°C	-20~+50	-20~+50	-20~+50
Weight, g	≤ 580	≤ 580	≤ 580
Dimension, mm	216x76x46	216x76x46	216x76x46
Body Material	Magnesium Alloy	Magnesium Alloy	Magnesium Alloy
