OVERVIEW

Key Advantages and Features

• Fast Engagement Magnification: 1.5X–4X / 1.5X–5X range ideal for short-range tactical and hunting situations.
• High-Contrast Imaging: Fully coated optics (broadband or wide-band green) ensure bright, clear views.
• Multi-Color Reticle Illumination: Red, green, and blue illumination with 3-level brightness for all lighting conditions.
• Built to Withstand Abuse: Shockproof, nitrogen-filled, waterproof, and fogproof construction with a single-piece tube body.
• Precision Adjustments: 1/4″ click value at 100 yards and reliable external turret controls.
• Power Efficient: Powered by a standard CR2032 battery for long operational runtime.

Application Scenarios:

• Ideal for AR-platform rifles, lever-action setups, and short-barrel builds, these scopes thrive in scenarios like close-quarters tactical drills, hog hunting in thick brush, or 3-gun matches.
• The illuminated red, green, and blue reticles with 3 brightness levels enhance visibility in both day and low-light environments, making them reliable for dawn patrols or twilight range sessions.

Customizable Features

• Supports optional etched glass reticles (MOA dot or traditional), diopter adjustment, and reticle illumination choices to meet specific mission profiles or visual preferences.
• OEM/ODM services are available for reticle design and turret adjustment schemes.

Parameters

Product Code	CHX1.5-4X30BE
Magnification Range	1.5X – 4X
Weight	667g
Length	255mm
Illumination	Red, Green, Blue with 3 brightness levels each
Objective Lens Diameter	30mm
Adjustment Method	External manual adjustment wheel
Adjustment Range	1/4 inch click at 100 yards
Reticle Type	Etched Glass reticle (optional)
Reticle Material	Glass
Coating	Broadband green coating
Shockproof	Yes
One-piece Tube Construction	Yes
Diopter Adjustment	Yes
Nitrogen-filled/Waterproof/Fogproof	Yes
Battery Type	1 x CR2032
