OVERVIEW

Key Advantages and Features

• Multi-Function Measurement Suite: Measures distance (up to 2000m), object speed (0–300 km/h), vertical height, and inclination angle (±90°)—all in one device. Perfect for dynamic field requirements.
• Fast & Accurate Scanning: Features continuous scan mode, allowing real-time tracking of moving objects—ideal for hunters following game or golfers locking onto a flagstick.
• Precision You Can Trust: Delivers readings with ±1 m + D×0.3% error margin, ensuring confidence whether you’re aligning fence posts or calculating shooting range drop-offs.
• User-Centric Design: 6x magnification with a wide 6.0° field of view. Diopter adjustment ±6°, suitable for glasses wearers. Intuitive distance unit switching (meters/yards). Compact dimensions (104×74.4×40.5 mm) and lightweight for one-handed use
• Built for the Field: IP54 dust and splash protection. -10°C to 50°C operating range. Long battery life (30,000 measurements per full charge) with 750mAh rechargeable Li-ion battery (USB-C). Laser class 1 / 905 nm wavelength—safe and compliant.

Application Scenarios

• The RB variant (up to 2000m) is ideal for long-range hunting, mountain surveying, or drone-based distance estimation, especially in open terrain.
• The B variant (up to 600–1500m) is perfect for golf course targeting, tree height evaluation, or construction layout measurements in urban or natural environments.
• Additional functions such as flagpole locking, height measurement, and angle ranging (±90°) enhance its usability across both leisure and professional outdoor applications.

Customizable Features

• OEM logo printing on housing and buttons
• Color shell customization or texture finishes
• Private-labeled packaging or user guide branding
• Custom firmware options for branded user interface
• MOQ supported for outdoor optics brands, hunting gear distributors, and engineering instrument suppliers.

Parameters

Product Code	SHDL-D600
Measuring Range	B: 3~600m/1000m/1500m; RB: 3~1000m/1500m/2000m
Magnification	6X ±5%
Field of View	6.0° ±10%
Scanning Ranging Function	✓
Reading Error	±(1.0m ± D×0.3%)
Speed Measurement Accuracy	±5 Km/h
Speed Measurement Range	0~300 Km/h
Height Measurement	✓
Flagpole Locking	✓
Magnetic Attraction	×
Scan Distance Measure	×
Angle Range	±90°
Diopter Adjustment Range	±6°
Units of Distance	m / Y
Objective Caliber	23.7 mm
Eyepiece Caliber	15.0 mm
Exit pupil Caliber (mm)	3.7±0.5 / 3.9±0.5
Battery	750mAh Li-ion
Charge-discharge Time	800 times
Operating Times	30000 times (at full charge)
Protection Grade	IP54
Operating Temperature	-10℃ ~ 50℃
Battery Life	Single Measuring 30000 times after one time full charging
Laser Level	Class 1
Laser Wavelength	905 nm
Dimensions	104×74.4×40.5 mm
