1-6x IPX7 Waterproof LPVO Rifle Scope Self-Locking Turret XIX1-6X24IR
This 1-6x LPVO is designed for tactical professionals, hunters, and 3-gun competitors who need a true 1x optic for close-range speed and 6x magnification for mid-range accuracy. With 24mm objective lens, 23.5° low-power FOV, and 136 – 98mm eye relief, it provides both situational awareness and target clarity. Its 300 MOA elevation/windage range and ½ MOA click adjustments give shooters wide flexibility, while IPX7 waterproofing and 1200G recoil resistance ensure field reliability.
OVERVIEW
Key Features & Advantages
- Magnification range: 0.98x–6.05x for close-to-mid-range versatility.
- Illuminated reticle: Side turret adjustment with self-locking system.
- Precision adjustment: ½ MOA clicks, 300 MOA elevation & windage.
- Bright, clear optics: Fully multi-coated green lenses for 150″ resolution clarity.
- Durability tested: IPX7 waterproof, 1200G recoil resistance (150 cycles).
- Comfortable eye relief: 136mm at 1x, 98mm at 6x.
- Compact & balanced: 220mm length, 550g weight.
- Reliable accuracy: Travel deviation ≤0.25 MOA, image drift ≤1 MOA.
Application Scenarios
Tactical & AR Platforms: A 1-6x LPVO scope for AR-15 rifles and carbines, with self-locking turrets for secure adjustments under recoil.
Hunting Applications: A rugged 1-6x LPVO for deer and hog hunting, with illuminated reticle visibility from dawn to dusk.
3-Gun Competition & Sports: A 1-6x LPVO for competitive shooting, balancing fast 1x transitions with 6x zoom precision.
Outdoor Security & Law Enforcement: Trusted as a waterproof LPVO for patrol rifles, reliable under rain, mud, and heavy use.
Customizable for Your Brand
Logo and firmware customization available
OEM/ODM support with low MOQ
Custom language interface and startup screens
Customization Options
- OEM/ODM branding (logo, private-label packaging).
- Reticle designs (BDC, red/green illumination).
- Housing finish (matte black, desert tan, camouflage).
- Mount base compatibility (Picatinny, Weaver, quick-detach).
Parameters
| Product Code | XIX1-6X24IR |
| Magnification (Low) | 0.985x |
| Magnification (High) | 6.055x |
| Objective Lens Diameter (mm) | 24 |
| Field of View (Low) | 23.5° |
| Field of View (High) | 4.8° |
| Exit Pupil Diameter (Low) | 15.5 mm |
| Exit Pupil Diameter (High) | 4.6 mm |
| Eye Relief (Low) | 136 mm |
| Eye Relief (High) | 98 mm |
| Length (mm) | 220 mm |
| Net Weight (g) | 550 g |
| Click Value | 1 Click = 1/2 MOA |
| Diopter Adjustment | +2.5 / -2 |
| Illuminated | Yes |
| Illumination Adjustment Position | Side turret |
| Turret Type | Self-locking |
| Elevation Adjustment Range (UP/D) | 300 MOA |
| Windage Adjustment Range (R/L) | 300 MOA |
| Lens Coating | Fully Multi-coated Green |
| Resolution | 150″ |
| Shock Resistance | 1200G / 150 times |
| Waterproof Level | IPX7 |
| Travel Deviation (Effective Range) | 0.25 MOA |
| Image Drift | 1 MOA |
Looking for a premium 1-6x LPVO supplier with rugged durability and OEM/ODM customization?
With this, your LPVO catalog is very strong:
- Entry models (1-5x, 1.2-6x, non-illuminated) → budget & training.
- Mid-tier (fixed 3x, 4x prism, 4x rugged illuminated) → compact reliability.
- Premium (1-6x aerospace aluminum, 1-6x IPX7 self-locking) → tactical & competition.
Contact us today for wholesale orders and private-label branding opportunities.
