OVERVIEW

Key Advantages and Product Features

• Flexible Zoom Range (4–16X / 6–24X): Allows both mid-range and extreme-distance aiming with precision
• Large 50 mm Objective Lens: Enhances low-light performance and image brightness
• Wide Eye Relief (89–76 mm): Accommodates heavy recoil rifles while maintaining comfort
• Metal Housing & Precision Mounting: Built with 25.4 mm tube for 11mm or 20mm rails
• Compact & Balanced: Lengths under 380 mm, weights below 700 g—perfect for modern tactical rifles
• Field of View: 5.6°–1.37° (4–16X), 3.2°–1.01° (6–24X) for optimal situational awareness and target tracking
• Exit Pupil Adaptability: Ranges from 12.5 mm down to 2.08 mm for precise light control across magnifications
• Grade RG-5 Brightness System: Supports illuminated reticle for use in dusk/dawn or shaded environments

Application Scenarios:

• Big game hunting in open terrain
• Precision Rifle Series (PRS) competitions
• Tactical range day drills and sniper training
• Long-distance pest control or predator management
• Marksman role in military/law enforcement deployments

Customizable Features

• Mount type options: 11mm / 20mm rail
• Brightness control: Grade RG-5 reticle illumination
• Custom finish/logo engraving for OEM/ODM orders
• Adjustable zero-reset turret system upon request
• Retail-ready packaging customization: 25×8×6 cm box

Parameters

Product Code	TEF4-16X50AOEG
Magnification	4-16X
Material	Metal
OBJECTIVE LENSE	50mm
Exit Pupil Diameter	12.5 – 3.12 mm
Length	375 mm
Tube Diameter	25.4 mm
Eye Relief	89 – 76 mm
Field of View	5.6° – 1.37°
Mount type	20mm, 11mm
Weight	670G
Brightness control	Grade RG-5
Package size of single product	25X8X6 cm
Gross weight per piece	1KG
