OVERVIEW

Key Features & Advantages

🔭 Magnification Range: 1X–8X – Enables both reflex-style engagement and precision targeting

🌐 Field of View: Ultra-wide 127.5 ft down to 15.7 ft @100 yds (22°–3°)

🔬 Glass-Etched Reticle – Customizable, sharp, and illuminated-ready (optional)

💧 Waterproof, Fogproof, Shockproof – Withstand extreme outdoor use

👁 Generous Eye Relief – 100mm, ensuring safety with high-recoil rifles

⚙️ ½ MOA Click Adjustments – Precise elevation and windage control with 120 MOA total range

💪 Robust One-Piece Construction – Durable yet lightweight at just 540g

🌙 Low-Light Capable – Ready for dusk/dawn operations when equipped with illumination (optional)

Application Scenarios

This LPVO scope is optimized for:

• Tactical use on AR-15 rifles, where a true 1x setting ensures rapid target acquisition at close quarters
• Pig or predator hunting, with quick magnification transitions for scanning terrain
• 3-Gun and dynamic competition shooting, demanding both speed and accuracy

Customization Options

This scope is ready for OEM & ODM custom branding and specification tweaks to match your brand identity and market demands:

• Custom reticle designs (MOA, MIL, BDC variants)
• Laser-engraved logo for private labeling
• Optional finish colors beyond the default
• Custom packaging and turret options (MOQ negotiable)

📩 Let’s build a scope tailored to your customers—ask us about white-label opportunities.

Parameters

Product Code	XIF1-8X24
Model Number	1-8X24
Magnfication	1X-8X
Objective Dia.	24mm
Tube Dia.	30mm
Field of view@100yards	127.5-15.7
Field of view (°)	22°-3°
Eye Relief (mm)	100
Exit Pupil (mm)	10.5/3
Click Value	0.5
Illuminated  or not
W/E Adjustment Range	120
side focus
Length（mm）	270
Weight（g）	540
Reticle Type (Etched / Wire)	Glass-Etched
Construction type (1 / 2 Piece)	One-piece
Waterproof (Y / N)	Y
Fogproof (Y / N)	Y
Shockproof (Y / N)	Y
