OVERVIEW

Key Advantages and Features

• Versatile Magnification: 1.5x to 12x zoom range supports both close-quarters acquisition and distant precision.
• Large 56mm Objective Lens: Maximizes light transmission, providing exceptional image brightness and clarity.
• Rear Focal Plane Reticle: Ensures consistent reticle size across magnifications for intuitive aiming.
• Field-Ready Durability: Nitrogen-filled and waterproof, finished in rugged black matte.
• Fast-Focus Eyebell: Enables quick diopter adjustment and crisp reticle clarity.
• Precise Adjustments: 1/4 MOA click value with >25 MOA elevation and windage range.
• Wide Field of View: 11 ft – 40 ft at 100 yards, with parallax adjustment from 10 yards to infinity.

Application Scenarios:

• Big game hunting in low-light conditions
• Long-range targeting in mountainous or wooded terrain
• Dawn-to-dusk patrols or surveillance
• Precision shots from blinds or elevated positions

Customizable Features

• Reticle style (duplex, illuminated MIL/MOA)
• Laser-engraved OEM branding
• Multi-language instruction manual
• Reticle in front or rear focal plane (upon request)

Parameters

Product Code	XIF1.5-12X56IR
Model	1.5-12x56IR
Magnification	1.5x – 12x
Objective Lens Diameter	56 mm
Ocular Lens Diameter	35 mm
Field of View (@100 yds)	11 ft – 40 ft
Exit Pupil Diameter	37 mm – 4.5 mm
Focusing Type	Fast Focus Eyebell
Length	352 mm
Weight	755 g
Eye Relief	3.5″
Waterproof	Yes
Exterior Finish	Black Matte
Tube Diameter	30 mm
Windage Adjustment	>25 MOA
Elevation Adjustment	>25 MOA
Click Value	1/4″
Diopter Compensation	±2
Parallax Adjustment	10 yds – ∞
Lens Coating	FMC
Illumination	Yes
Reticle Position	Rear Focal Plane
