OVERVIEW

Key Advantages and Features

• Multi-Axis Field Measurement: Captures height, horizontal and vertical distance, incline angles, and object speed (0–300 km/h)—delivering complete situational data for field personnel and outdoor users.
• Fast, Accurate, and Intuitive: With <0.5s response time (64 ms under 120 m), and ±1 m ± D×0.3% accuracy, this rangefinder ensures near-instant feedback in real-world usage.
• Visual and Physical Feedback: Includes vibration confirmation and flagpole lock function to give the user clear indication when target lock is achieved—useful during hunting, surveying, or mobile observation.
• Built for Harsh Conditions: IP54-rated protection keeps dust and light rain at bay. Wide diopter adjustment (±6°) supports glasses wearers and variable lighting. Class 1 laser (905 nm) ensures safety while maintaining effective power
• Long Runtime, Fast Charging: Features a 750mAh rechargeable Li-ion battery, lasting 20,000 measurements per full charge, and Type-C charging (DC 5V / 0.5A) for fast field turnaround.
• Magnetic Base for Easy Mounting: Built-in magnet enables quick attachment to metal equipment or tactical brackets, freeing hands during extended observation or repeated measurements.

Application Scenarios

• The 3–1500m distance range allows this device to excel in long-range perimeter observation, hunting from elevated positions, or line-of-sight planning in forestry and construction.
• The inclusion of vibration prompt + flag locking makes it well-suited for users needing precise, handheld distance confirmation in windy, uneven, or tactical terrain.
• Slope and dip measurement (±90°) enables accurate data for roofers, landscape architects, or tree height inspectors working in variable elevation.

Customizable Features

• OEM logo printing on housing and buttons
• Color shell customization or texture finishes
• Private-labeled packaging or user guide branding
• Custom firmware options for branded user interface
• MOQ supported for outdoor optics brands, hunting gear distributors, and engineering instrument suppliers.

Parameters

Product Code	SHDL2000D
Measurement Range	B: 3~700m/1000m/1500m
Accuracy	±(1.0m ± D×0.3%)
Unit	m (Meter), Y (Yard)
Measuring Speed	<0.5s (<120M 64ms; >120M 460ms)
Scanning Mode	×
Speed Measurement Accuracy	±5 km/h
Speed Measurement Range	0~300 km/h
Height Measurement	✓
Slope Measurement	✓
Dip Measuring Range	±90°
Flagpole Locking	✓
Azimuth Mode	×
Horizontal and Vertical Distance Measurement	✓
Vibration Prompt	✓
Magnetism	✓
Golf Compensation Mode	×
Fog Mode	×
Magnification	6X ±5%
Field of View	7.0° ±5%
Objective Caliber	23.5 mm
Eyepiece Caliber	15 mm
Exit Pupil Caliber (mm)	3.7±0.5 / 4.0±0.5 / 3.9±0.5
Diopter Adjustment Range	±6°
Laser Level	Class 1
Laser Wave Length	905 nm
Protection Grade	IP54
Battery	3.7V 750mAh Li-ion
Battery Life	Single measuring 20000 times after one full charge
Charging Specifications	DC5V 0.5A Type-C
Dimension	112 × 70 × 40 mm
