OVERVIEW

Key Advantages and Features

• 5-25× Zoom with 56mm Objective Combines optical clarity with powerful ranging functionality
• Dual illuminated reticles Ideal for crosshair targeting and tactical alignment
• ±0.5m distance accuracy & ±90° angle range Suitable for topographic mapping and ballistic calculations
• CR123A battery powered Ensures long runtime in field environments
• 92–95mm long eye relief Comfortable even with glasses
• -30°C cold-resistant operation Reliable in extreme cold and outdoor deployments
• 1/8 MOA adjustments with ±41.5 MOA range Supports micro-level adjustments at long distances
• IPX-rated waterproof housing Resists fog, rain, and rough usage

Why B2B Buyers Choose Us

• Integrates spotting scope-level optics with laser precision, ideal for dual-function procurement
• Durable tactical housing ensures performance under demanding conditions
• Custom branding and flexible supply options support private label and OEM needs
• Reduces buyer’s post-sale issues thanks to high reliability and intuitive usability

Customizable Features

• Ranging distance configurations: 1000m / 2000m / 3000m
• Brand logo customization: Available via laser engraving or pad printing
• Body color: Tactical black, desert tan, olive drab, or custom
• Mounting interfaces: 30mm / 40mm tube compatibility

Contact us for tailored configurations or private label solutions.

Parameters

Product Code	HOY5-25X56
Magnification × Objective Lens Diameter	5-25×56
Reticle Type	Double Reticles
Field of View	1.0°–4.0°
Eye Relief	92–95 mm
Exit Pupil Diameter	11.2–2.24 mm
Diopter Adjustment	±3D
Click Value	1/8 MOA
Adjustment Range	±41.5 MOA (1 MOA = 0.0167°)
Laser Wavelength	905 nm
Laser Power	<1 mW
Laser Class	CLASS 1
Ranging Distance Options	6–1000 m / 6–2000 m / 6–3000 m
Ranging Accuracy	±0.5 m
Angle Measurement Range	±90°
Dimensions	382.5 × 75 × 87 mm
Weight	850 g
Battery Type	CR123A
Low Temperature Operating Limit	-30°C
Tube Diameter	30 / 40 mm
