OVERVIEW

Product Features and Benefits

• Uncooled infrared sensor (384×288 @ 12μm pixel pitch) with <35 mK thermal sensitivity
• 25 mm lens, F1.0 aperture for maximum heat signature collection and detail
• Detection range up to 1900 meters, with target-specific depth profiles (e.g., poultry: 296 m, humans: 1488 m)
• OLED display with 1024×768 resolution ensures sharp thermal visualization
• Four imaging modes: Black Hot, White Hot, Red Hot, Fusion
• Digital zoom: 1x, 2x, 4x, 8x; adjustable brightness & contrast (1–5 levels)
• Integrated laser pointer and gun-laying reticle for operational accuracy
• TYPE-C data interface for fast file transfer or external display
• Replaceable polymer or lithium battery, runtime 6.5 hours, supports external charging
• Waterproof IP67, shock resistant, and temperature rated for -20°C to +55°C
• Lightweight and compact for field mobility with handheld or tripod use

Ideal Applications

Ideal for wildlife detection, farm surveillance, border patrol, and nighttime search and rescue, the FUS25 offers highly adaptive viewing modes—Black Hot, White Hot, Red Hot, and Fusion—plus a built-in laser pointer and gun-laying reticle for tactical precision. Depth perception is optimized for targets like livestock (up to 1392 m), humans (1488 m), and small animals (378 m), making it a versatile tool for both field operations and environmental monitoring.

Customization Options

Supports OEM branding, interface localization, and custom firmware tuning. Built to accommodate tactical distributors, government contracts, and private-label optics programs with flexible MOQ requirements and international export readiness.

Parameters

thermal imagery	Product Code	FUS25
	Sensor Type	Uncooled type detector
	Maximum Image Size	384 X 288
	Pixel size	12 μm
	Response band	8~14 pim
	NETD	< 35 mk ( @25°C, F# = 10)
	MRTD	500 mk
	Infrared lens focal length	25 mm
	detection range	1900 m
	FOV	10.7° X 8°
	Lens aperture value	F1.0
	frame frequency	25 (BT.656)，50 (YUV + RAW)
image display	displayer	OLED
	monitor resolution	1024*768
	image model	Black heat mode, white heat mode, red heat mode, fusion mode
	Digital zoom	1X,2X,4X,8X
	Screen brightness adjustment	1–5
	contrast control	1–5
	Optical magnification	1X
system function	diopter regulation	have
system function	diopter regulation	have
	Laser indication	have
	gun-laying reticle	have
	data interface	TYPE-C
system parameter	storage	have
	the duration of flight	6.5 h
	power supply mode	Replaceable internal battery ,; can support external charging
	type of battery	Polymer battery (or lithium battery)
	operating temperature	-20 °C~55 °C
	level of protection	IP67
depth perception	birds	54m
Detection range		125m
depth perception	poultry	88m
Detection range		296m
depth perception	small animal	108m
Detection range		378m
depth perception	livestock	389m
Detection range		1392m
depth perception	people	405m
Detection range		1488m
